Common Faults of Core Winding Machines and Their Solutions!

How to solve some problems when the iron core winding machine malfunctions? Let's take a look together with the editor of the iron core winding machine below!
1、 The iron core winding machine does not operate when it is first started:
1. The main power supply is not connected. Check the external power supply and power on from the beginning;
2. Control the power supply without connecting the universal key switch, turn on the power or close the switch inside the distribution cabinet;
3. Press the pause button again to make it pop up;
4. Press the emergency stop button to activate it;
5. Replacement of damaged PLC;
6. Connect the power cord to an independent power source from scratch with other devices.
2、 The turntable of the iron core winding machine does not rotate:
1. The frequency converter is burnt out, and the phenomenon is no apparent replacement;
2. The parameters of the frequency converter are set incorrectly according to the requirements from scratch;
3. If the turntable chain cracks, adjust the spacing between the large and thin chain wheels, connect the chain, and replace the chain if it is damaged;
4. The connection between the turntable reducer and the sprocket is abnormal. Replace the connecting flat key;
5. Replacement of the turntable reducer due to its own malfunction;
6. The knob is damaged and the chassis does not rotate (E-type equipment). Replace it;
7. PLC does not have output replacement;
8. Use a multimeter or shaking table to check for missing items or breakdown of the turntable motor itself. If it cannot be repaired on site, replace the motor.
